VERKLINE WAS-602 Rear Lightweight Tubular Subframe Kit for TOYOTA GR Yaris (XP210) 2020-
This item is considered special order and is not available for immediate pickup or dispatch. Price and ETA may vary. Please note that no returns, cancellations, or refunds allowed on special orders.
VERKLINE WAS-602 Rear Lightweight Tubular Subframe Kit for TOYOTA GR Yaris (XP210) 2020-
ATOMIC-SHOP UAE
26th Street - Al Quoz Industrial Area 2
Dubai DU
United Arab Emirates
Product functionalities:
- Additional (revised) suspension mounting points for improved suspension kinematics for lowered cars with racing or track purpose
- Bump steer adjustability
- One mounting subframe position eliminates subframe shifting under the car. No need for subframe locking kit / deadset collar kit (weight savings)
- Increases chassis rigidity for improved handling performance. No need for additional lower bar/member brace (weight savings)
- Better access to car underbody
Features:
- Lighter than OEM by 6 kg.
- Compatible with both OEM and Verkline wishbones.
- Made from T45 super strong piping..
- Delivered painted (powder coated) black.
What is included
- One rear subframe powder coated black with lower brace.
- Set of adjustment shims for kinematics adjustment.
- One black polyurethane mount for the rear differential.
- Set of mounting bolts.
- Adjustment Wrench.
- Printed install instructions (9 pages).
Notice: If you want to use modified suspension mounting points that are available on this subframe, you need to use also Verkline wishbones - WAS-621 and WAS-622 OEM wishbones won’t work there. For standard OEM pickup on subframe it is possible to use OEM wishbones.
Notice 2: Not all aftermarket exhaust systems will fit with this subframe. There might be some rework on aftermarket exhaust necessary.
Notice 3: Installation of this rear insert kit will introduce some additional some NVH (noise, vibration, and harshness) transfer into the cabin.
