SPEED ENGINEERING 13583 Brake Cooling System for AUDI TTRS (8J)

Description SPEED ENGINEERING 13583 Brake Cooling System for AUDI TTRS (8J)

The SPEED ENGINEERING 13583 Brake Cooling System is designed for the AUDI TTRS 8J to improve brake cooling at the front axle. The system uses the existing air duct in front of the wheel and extends airflow routing around the wheel toward the brake ventilation outlet.

The outlet mounts to the wishbone and directs airflow toward the centre of the brake disc / brake rotor regardless of wheel position. The system is secured using existing locking pins without permanent vehicle modifications. Because the system does not pivot with the wheel, the hose is not under constant strain, and a short hose reduces airflow losses.

Road Use: Motorsport parts are not approved for road use.

Installation Note: Models vary slightly in wheel position, chassis geometry, and wheel and tyre combinations. In some cases, the wheel may lightly touch at full steering lock, and the final quarter of the steering travel should be avoided.

• Uses the existing front air duct and an extension to guide airflow around the wheel
• Prevents uncontrolled air swirl inside the wheel arch
• Airflow direction remains independent of wheel position
• Short hose routing reduces airflow losses and hose strain

Specifications:

• Air Hose Length: 1 metre total; 40 cm hose routing on each side

Kit comes with:

• 1x air duct inlet for front axle left
• 1x air duct inlet for front axle right
• 6x fixing screws with washers
• 1x air duct outlet for front axle left
• 1x air duct outlet for front axle right
• 1x air hose, 1 metre
• 4x hose clamps
