JE 284779 Piston Kit (82.50 mm Bore, 1.165 in. CH, -3.70 CC) for VW 2.0T FSI Engine

AED 4,020.93

Tax included. Shipping calculated at checkout

JE PISTONSP/N: 284779 GTIN: 193564044846
Available for order at Partners Worldwide Usually ready in 1-2 weeks updated 23.06.2026
Quantity:

This item is considered special order and is not available for immediate pickup or dispatch. Price and ETA may vary. Please note that no returns, cancellations, or refunds allowed on special orders.

Pickup available at ATOMIC-SHOP UAE Usually ready in 1 hour

JE 284779 Piston Kit (82.50 mm Bore, 1.165 in. CH, -3.70 CC) for VW 2.0T FSI Engine

ATOMIC-SHOP UAE

Pickup available, usually ready in 1 hour

26th Street - Al Quoz Industrial Area 2
Dubai DU
United Arab Emirates

+97143580877

ATOMIC-SHOP UAE (RABDAN Motorsport)

Pickup available, usually ready in 1 hour

14 10b St - Al Quoz Industrial Area 3
Dubai DU
United Arab Emirates

+971559861650

Description JE 284779 Piston Kit (82.50 mm Bore, 1.165 in. CH, -3.70 CC) for VW 2.0T FSI Engine

JE Pistons applies over 75 years of experience to its range of premium forged racing pistons for European, import, and sport compact applications.

Engineered, forged, and machined 100% in the USA, these pistons are Designed for each specific engine and racing application to provide durability and performance.

  • Forged from 4032 aluminum for tensile strength and minimal thermal expansion
  • Proprietary Forged Side Relief design minimizes friction and power loss while reducing skirt width, weight, and Wrist Pin length
  • Application-dependent skirt coating reduces friction, piston skirt and cylinder Wall wear, and operating noise
  • Application-dependent accumulator groove reduces combustion gas pressure and Piston Ring flutter while improving ring seal

Specifications:

  • Piston Series: JE Pistons
  • Cylinder Head: 2.0L GOLF FSI
  • Bore Diameter: 82.50 mm
  • Piston Head Type: Dish
  • Compression Height: 1.165 in
  • Piston Volume: -3.70 cc
  • Piston Material: 2618
  • Piston Quantity: 4
  • Forging Type: Round
  • Piston Average Weight: 299 g
  • Ring Set Included: Yes
  • Top Compression Ring Thickness: 0.0400 in
  • Second Compression Ring Thickness: 0.0480 in
  • Oil Ring Thickness: 0.111 in
  • Wrist Pin Outer Diameter: 0.787 in
  • Wrist Pin Length: 2.250 in
  • Wrist Pin Wall Thickness: 0.180 in
  • Engine Detail: 2.0T FSI 04-08 20 mm Pin
  • Intake Depth: 0.155 in
  • Intake Diameter: 1.500 in
  • Intake Angle: 23
  • Exhaust Depth: 0.030
  • Exhaust Diameter: 1.250
  • Exhaust Angle: 21
  • Top Groove Width: 0.04000 in
  • 2nd Groove Width: 0.04800 in
  • Oil Groove Width: 0.11100 in

Fitment

  • AUDI A4 (8E2, B6) 2.0 2000 - 2004
  • AUDI A4 (8E2, B6) 2.0 FSI 2002 - 2004
  • AUDI A4 (8E2, B6) 2.5 TDI 2001 - 2002
  • AUDI A4 (8E2, B6) 2.5 TDI 2002 - 2004
  • AUDI A4 (8E2, B6) 3.0 2000 - 2004
  • AUDI A4 (8E2, B6) 3.0 2001 - 2004
  • AUDI A3 Sportback (8PA) S3 quattro 2008 - 2013
  • AUDI A3 Sportback (8PA) S3 quattro 2008 - 2013
  • AUDI A4 (8EC, B7) 1.9 TDI 2004 - 2008
  • AUDI A4 (8EC, B7) 2.0 2004 - 2008
  • AUDI A4 (8EC, B7) 2.0 TDI 2004 - 2008
  • AUDI A4 (8EC, B7) 2.0 TDI 2006 - 2008
  • AUDI A4 (8EC, B7) 2.0 TDI 2004 - 2008
  • AUDI A4 (8EC, B7) 2.0 TDI 2005 - 2006
  • AUDI A4 (8EC, B7) 2.0 TDI quattro 2006 - 2008
  • AUDI A4 (8EC, B7) 2.0 TDI quattro 2006 - 2008
  • AUDI A4 (8EC, B7) 2.0 TFSI 2004 - 2008
  • AUDI A4 (8EC, B7) 2.0 TFSI 2005 - 2008
  • AUDI A4 (8EC, B7) 2.0 TFSI 2006 - 2008
  • AUDI A4 (8EC, B7) 2.0 TFSI quattro 2004 - 2008
  • AUDI A4 (8EC, B7) 2.0 TFSI quattro 2005 - 2008
  • AUDI A4 (8K2, B8) 1.8 TFSI 2011 - 2015
  • AUDI A4 (8K2, B8) 1.8 TFSI 2007 - 2012
  • AUDI A4 (8K2, B8) 1.8 TFSI 2008 - 2015
  • AUDI A4 (8K2, B8) 1.8 TFSI quattro 2011 - 2015
  • AUDI A4 (8K2, B8) 1.8 TFSI quattro 2008 - 2012
  • AUDI A4 (8K2, B8) 2.0 TDI 2011 - 2015
  • AUDI A4 (8K2, B8) 2.0 TDI 2007 - 2015
  • AUDI A4 (8K2, B8) 2.0 TDI 2007 - 2015
  • AUDI A4 (8K2, B8) 2.0 TDI 2008 - 2012
  • AUDI A4 (8K2, B8) 2.0 TDI 2008 - 2015
  • AUDI A4 (8K2, B8) 2.0 TDI 2008 - 2015
  • AUDI A4 (8K2, B8) 2.0 TDI 2013 - 2015
  • AUDI A4 (8K2, B8) 2.0 TDI 2013 - 2015
  • AUDI A4 (8K2, B8) 2.0 TDI quattro 2011 - 2015
  • AUDI A4 (8K2, B8) 2.0 TDI quattro 2008 - 2012
  • AUDI A4 (8K2, B8) 2.0 TDI quattro 2008 - 2015
  • AUDI A4 (8K2, B8) 2.0 TDI quattro 2013 - 2015
  • AUDI A4 (8K2, B8) 2.0 TDI quattro 2013 - 2015
  • AUDI A4 (8K2, B8) 2.0 TFSI 2008 - 2015
  • AUDI A4 (8K2, B8) 2.0 TFSI 2008 - 2013
  • AUDI A4 (8K2, B8) 2.0 TFSI 2013 - 2015
  • AUDI A4 (8K2, B8) 2.0 TFSI 2013 - 2015
  • AUDI A4 (8K2, B8) 2.0 TFSI flexible fuel 2009 - 2015
  • AUDI A4 (8K2, B8) 2.0 TFSI flexible fuel quattro 2009 - 2015
  • AUDI A4 (8K2, B8) 2.0 TFSI quattro 2008 - 2015
  • AUDI A4 (8K2, B8) 2.0 TFSI quattro 2013 - 2015
  • AUDI A4 (8K2, B8) 2.0 TFSI quattro 2013 - 2015
  • AUDI A3 Sportback (8VA, 8VF) S3 quattro 2012 +
  • AUDI A3 Sportback (8VA, 8VF) S3 quattro 2013 +
  • AUDI A3 Sportback (8VA, 8VF) S3 quattro 2014 +
  • AUDI A3 Sportback (8VA, 8VF) S3 quattro 2016 +
  • AUDI A3 Sportback (8VA, 8VF) S3 quattro 2016 +
  • AUDI A3 Convertible (8V7, 8VE) S3 quattro 2014 +
  • AUDI A3 Convertible (8V7, 8VE) S3 quattro 2014 +
  • AUDI A3 Convertible (8V7, 8VE) S3 quattro 2016 +
  • AUDI A3 Convertible (8V7, 8VE) S3 quattro 2016 +
  • VW JETTA III (1K2) 2.5 2006 - 2010
  • VW JETTA IV (162, 163, AV3, AV2) 2.0 TSI 2010 +
  • VW JETTA IV (162, 163, AV3, AV2) 2.0 TSI 2012 +
