GARRETT 908829-0001 External Wastegate GVW-50 1 Bar (14.5 PSI) Red Photo-0

GARRETT 908829-0001 External Wastegate GVW-50 1 Bar (14.5 PSI) Red

Sale priceAED 2,613.87

Tax included. Shipping calculated at checkout

GARRETTP/N: 908829-0001
Quantity:

This item is considered special order and is not available for immediate pickup or dispatch. Price and ETA may vary. Please note that no returns, cancellations, or refunds allowed on special orders.

Pickup available at ATOMIC-SHOP UAE Usually ready in 1 hour

GARRETT 908829-0001 External Wastegate GVW-50 1 Bar (14.5 PSI) Red

ATOMIC-SHOP UAE

Pickup available, usually ready in 1 hour

26th Street - Al Quoz Industrial Area 2
Dubai DU
United Arab Emirates

+97143580877

Garrett External Wastegates regulate turbocharger shaft speed by venting exhaust gas around the turbine stage of the turbocharger. CFD optimized design maximizes flow and delivers optimum boost control. Advanced thermal optimization increases durability of the diaphragm. The cap design makes spring changes and serviceability of the entire GVW lineup easier and more reliable to perform.

Features

  • CFD tested for maximum flow and thermal efficiency
  • Optimized actuation stability and temperature resistance for superior durability
  • Replaceable valve and bushing components to increase service life
  • Robust design for easy diaphragm replacement
  • Liquid-cooled actuator ports for use on severe applications (up to 52% reduction in body temp)
  • Anodized aluminum actuator cover
  • Four Colors: Red / Blue / Black / Silver
  • Three Sizes: 40mm / 45mm | 50mm / 60mm
  • Springs / Fittings / Flanges / V-Bands included
  • Standard Base Pressure: 1 Bar / 14.5 PSI
  • Maximum Base Pressure:
    GVW-40: 25 PSI / 1.7 Bar
    GVW-45 / GVW-50 / GVW-60 23 PSI / 1.6 Bar
  • Minimum Base Pressure: 3 PSI / 0.2 Bar
